Applications
- • Permanent Installations
- • Main Reinforcement in small spaces
- • Portable Systems AV Presentations
- • Zone Delay and Fill Systems
- • Under Balcony Applications
Part Number
- • 13000284
Features
- 120° x 60° CMD (Coverage Matching Design) constant directivity horn
- Rotatable Horn System for horizontal cabinet mounting applications
- HF driver AMCDP (Active Mosfet Compression Driver Protection)
- LICC (Low Impedance Compensated Crossover) network
- 10 Suspension points
- 1 top pole mount, 1 bottom pole mount
Acoustical Specifications
- Frequency Response -10 dB: 67 Hz ÷ 20000 Hz
- Max SPL @ 1m: 127.5 dB
- Horizontal coverage angle: 120°
- Vertical coverage angle: 60°
- Directivity index; Q: 11
- System Sensitivity: 96.5 dB
- Nominal Impedance: 8 Ω
- Power Handling: 300 W
- Peak Power Handling: 1200 W
- Recommended Amplifier: 600 W
- Protections: Dynamic
- Crossover frequencies: 2200 Hz
Transducers
- Compression Driver: 1" HF driver, 1.5" voice coil
- Nominal Impedance: 8 Ω
- Input Power Rating: 25 W AES
- Sensitivity: 106 dB
- Woofer: 10" woofer, 2" voice coil
- Nominal Impedance: 8 Ω
- Input Power Rating: 250 W AES
- Sensitivity: 96 dB
Input Section
- Input connector: Speakon NL4
- Output connector: Speakon NL4
Cabinet
- Cabinet Material: 15 mm birch plywood construction
- Hardware: 8 x M8 back, 2 x M10 side
- Pole Mount/Cap: 1 top, 1 bottom
- Grille: custom perforated steel grille, epoxy powder coated, covered with polyurethane perforated cloth
- Colour: Black
Physical Specifications
- Height: 500 / 19.68 mm/inch
- Width: 300 / 11.81 mm/inch
- Depth: 298 / 11.73 mm/inch
- Net Weight: 15.8 / 34.83 kg/lbs
